Using Github Flavored Markdown in the Netlify CMS Preview Pane

Using Github Flavored Markdown in the Netlify CMS Preview Pane

Tobbe Lundberg's photo
Tobbe Lundberg

Published on Feb 11, 2021

4 min read

Document editing mode on Netlify CMS gives you two panes, one with the editor, and one with a preview. By using the global CMS object you can customize the preview. What we're going to do here is to make it render the markdown we write in the editor with react-markdown which we extend with the remark-gfm plugin to add support for Github Flavored Markdown (tables, strikethrough, etc).

Screenshot of Netlify CMS with GFM enabled preview

The way the preview customization works is you tell CMS what collection to use the custom preview for, and you give it a React component to use. You can only write old-school class components, and you have to use the createClass and h helper functions provided by NetlifyCMS.

Below is an example that creates a DocPreview React component and tells CMS to use that whenever it's showing a preview for a document in the "pages" category. The render() function uses the widgetFor() helper function (read more in the NetifyCMS docs) to get the default widget used to display the 'body' field, and nothing else. By default the preview will show all fields, like "title" etc, but here we're stripping those out.

<!DOCTYPE html>
<html>
  <head>
    <meta charset="utf-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0" />
    <title>Netlify CMS Example</title>
  </head>
  <body>
    <script src="https://unpkg.com/netlify-cms@^2.10.0/dist/netlify-cms.js"></script>
    <script>
      const DocPreview = createClass({
        render: function() {
          return this.props.widgetFor('body');
        },
      });

      window.CMS.registerPreviewTemplate("pages", DocPreview);
    </script>
  </body>
</html>

Another thing we can do is take the plain text from the "body" field and dump it in a <div> with the h() function, which is basically just an alias for React's createElement().

<!DOCTYPE html>
<html>
  <head>
    <meta charset="utf-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0" />
    <title>Netlify CMS Example</title>
  </head>
  <body>
    <script src="https://unpkg.com/netlify-cms@^2.10.0/dist/netlify-cms.js"></script>
    <script>
      const DocPreview = createClass({
        render: function() {
          const bodyText = this.props.entry.getIn(["data", "body"]);

          return h("div", {}, bodyText);
        },
      });

      window.CMS.registerPreviewTemplate("pages", DocPreview);
    </script>
  </body>
</html>

Since we're writing all the code in a basic index.html file without any kind of build tooling to support us we can't just do npm install and then include-ing the package. All we have to work with is the <script> tag. So whatever we want to use has to be in AMD or UMD module format. Thankfully react-markdown provides an umd build we can use straight from unpkg.com.

So just put unpkg.com/react-markdown@5.0.3/react-markdo.. in a <script> tag, and you'll have window.ReactMarkdown available, which is a React component you can use inside your custom render method.

With this you should be back to something that works the same as when we used widgetFor() except now we're using our own Markdown renderer, and not Netlify CMS's.

<!DOCTYPE html>
<html>
  <head>
    <meta charset="utf-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0" />
    <title>Netlify CMS Example</title>
  </head>
  <body>
    <script src="https://unpkg.com/netlify-cms@^2.10.0/dist/netlify-cms.js"></script>
    <script src="https://unpkg.com/react-markdown@5.0.3/react-markdown.min.js"></script>
    <script>
      const DocPreview = createClass({
        render: function() {
          const bodyText = this.props.entry.getIn(["data", "body"]);

          return h(window.ReactMarkdown, {}, bodyText);
        },
      });

      window.CMS.registerPreviewTemplate("pages", DocPreview);
    </script>
  </body>
</html>

The final step is to add support for Github Flavored Markdown, so we can do tables, strikethrough text and other things. The window.ReactMarkdown component takes a plugin prop that lets you augment it with different plugins, one which is remark-gfm. Unfortunately that package doesn't have a UMD build for us to use, it's only available in CJS (CommonJS) format. There is a tool called Browserify that takes CJS modules and converts them to modules that can be used by the browser. But it's a command line tool that you'd add to your tooling. Which, we don't have here. Thankfully someone turned it into a web service we can use! wzrd.in takes any npm package and tries to run it through Browserify and serves up the built package for you. First time it's run it takes a while, but after that it's cached and then it's much faster. Here's the link for the Browserified version of remark-gfm: wzrd.in/standalone/remark-gfm@1.0.0. Add that to a script tag and you'll have the plugin available at window.remarkGfm. Add that as a plugin to react-markdown and you're done!

<!DOCTYPE html>
<html>
  <head>
    <meta charset="utf-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0" />
    <title>Netlify CMS Example</title>
  </head>
  <body>
    <script src="https://unpkg.com/netlify-cms@^2.10.0/dist/netlify-cms.js"></script>
    <script src="https://unpkg.com/react-markdown@5.0.3/react-markdown.min.js"></script>
    <script src="https://wzrd.in/standalone/remark-gfm@1.0.0"></script>
    <script>
      const DocPreview = createClass({
        render: function() {
          const bodyText = this.props.entry.getIn(["data", "body"]);

          return h(window.ReactMarkdown, { plugins: [window.remarkGfm] }, bodyText);
        },
      });

      window.CMS.registerPreviewTemplate("pages", DocPreview);
    </script>
  </body>
</html>

Try writing some markdown jazzed up with a bit of gfm syntax to make sure everything works.

That's it. Hope this guide was helpful!
